| Items | Specifications | |
|---|---|---|
| Model | AAV144 | |
| Number of input channels | 16, isolated | |
| Input signal | 1 to 5 V | -10 to 10 V |
| Switching input signals | Input Signals can be set together for CH1 to CH16 | |
| Allowable input voltage | ±30 V | |
| Withstanding isolated voltage | Between input and system: 1500 V AC Withstanding voltage, For 1 minute (*1) | |
| Input resistance | Power ON | 1 MΩ |
| Power OFF | 200 kΩ | |
| Accuracy | ±4 mV | ±20 mV |
| Data update period | 10 ms | |
| Drift due to ambient temperature change | ±4 mV/10 ˚C | ±20 mV/10 ˚C |
| Maximum current consumption | 500 mA (5 V DC) | |
| Weight | 0.2 kg | |
| External communication | Pressure clamp terminal, MIL connector cable, Dedicated cable (KS1) | |
